Electric Stopper Cylinder (Made to Order) LEBQ
|
・Suitable for conveyor lines without an air supply
・Available rod end shapes: Chamfered type, roller type, and lever type ・Energy saving The power consumption at rod stoppage is reduced by 60%. ・Height and mounting methods are compatible with the stopper cylinder RSQ series. ・Easy setting Easy adjustment on site with a programless controller Applicable to the controller LEC series which allows detailed settings ・Compatible controllers: LECP6, LECP1 |
| Other Data |
|---|
| Series | Stroke (mm) | Pushing force (N) | Speed (mm/s) | Screw lead (mm) |
|---|---|---|---|---|
| LEBQ32 | 20 | 30 | 80 | 5 |
| LEBQ50 | 30 | 150 | 135 | 8 |
Electric Stopper Cylinder (Made to Order)LEBQ
| Series | Download |
|---|---|
| LEBQ32 |
|
| LEBQ50 |
|
Electric Actuator/LEF Series Support Guide LEFG
|
・A support guide that is designed to support workpieces with significant overhang
・Easy installation with the same outer dimensions as the LEF series body, Contributes to the reduction of design and assembly labor ・The standardly equipped sealing band prevents the scattering of grease and the entry of foreign matter from outside. |
| Other Data |
|---|
| Drive method | Model | Stroke (mm) |
|---|---|---|
| Ball screw drive/S | LEFG16-S | 50 to 500 |
| Ball screw drive/S | LEFG25-S | 50 to 800 |
| Ball screw drive/S | LEFG32-S | 50 to 1000 |
| Ball screw drive/S | LEFG40-S | 150 to 1200 |
| Belt drive/BT | LEFG16-BT | 300 to 1000 |
| Belt drive/BT | LEFG25-BT | 300 to 2000 |
| Belt drive/BT | LEFG32-BT | 300 to 2000 |
| Belt drive/BS | LEFG25-BS | 300 to 2000 |
| Belt drive/BS | LEFG32-BS | 300 to 2500 |
| Belt drive/BS | LEFG40-BS | 300 to 3000 |
Electric Actuator/LEF Series Support GuideLEFG
| Model | Download |
|---|---|
| LEFG16-S |
|
| LEFG25-S |
|
| LEFG32-S |
|
| LEFG40-S |
|
| LEFG16-BT |
|
| LEFG25-BT |
|
| LEFG32-BT |
|
| LEFG25-BS |
|
| LEFG32-BS |
|
| LEFG40-BS |
|
