Piping Equipment (Tubing)
- Energy Saving
- By Industry ⁄ Process
- Applications
Nylon Tubing T
Fittings and Tubing » Tubing
-
・General pneumatic tubing
・Max. operating pressure: 3.0 MPa (T0604, at 20℃)
*1 Refer to the catalog for more information on using the product.
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color | Fluid |
|---|---|---|---|---|
| T/TIA | φ4，φ6，φ8，φ10 φ12，φ16 | φ1/8''，φ3/16''，φ1/4'' φ3/8''，φ1/2'' | Black, White, Red, Blue, Yellow, Green | Air, Water Turbine oil class 1 (ISO VG32)*1 |
Soft Nylon Tubing TS
Fittings and Tubing » Tubing
-
・Max. operating pressure: 1.7 MPa (TS0604, at 20℃)
*1 Refer to the catalog for more information on using the product.
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color | Fluid |
|---|---|---|---|---|
| TS/TISA | φ4，φ6，φ8，φ10 φ12，φ16 | φ1/8''，φ3/16''，φ1/4'' φ3/8''，φ1/2'' | Black, White, Red, Blue, Yellow, Green | Air, Water Turbine oil class 1 (ISO VG32)*1 |
Polyurethane Flat Tubing/Multi-core, Multi-color TU
Fittings and Tubing » Tubing
-
・Multi-core, multi-color specification
・Compact piping is possible.
・8 color variations
| Series | Tubing O.D. | Color | Number of cores | Fluid |
|---|---|---|---|---|
| TU | φ2，φ4，φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green, Clear, Orange | 2, 3, 4, 5, 6 | Air |
Soft Polyurethane Tubing TUS
Fittings and Tubing » Tubing
| Series | Tubing O.D. | Color | Fluid |
|---|---|---|---|
| TUS | φ4，φ6，φ8，φ10，φ12 | Black, White, Red, Blue, Yellow, Green, Translucent, Yellow-brown | Air |
Hard Polyurethane Tubing TUH
Fittings and Tubing » Tubing
-
・Superior restoring force compared to the nylon tubing
| Series | Type | Max. operating pressure | Tubing O.D. | Color | Fluid |
|---|---|---|---|---|---|
| TUH | Standardtype | 0.8 MPa (at 20°C) | φ4，φ6，φ8 φ10，φ12 | Black, White, Blue, Translucent | Air |
| TUH | High-pressuretype | 1.0 MPa (at 20°C) | φ4，φ6，φ8 φ10，φ12 | Black, White, Blue, Translucent | Air |
FEP Tubing (Fluoropolymer) TH/TIH
Chemical Liquid Valves/Fittings & Needle Valves/Tubing » Tubing
-
・Maximum operating pressure: 2.3 MPa (at 20°C)＊
・Food Sanitation Law compliant
・Compliant with the FDA’s (Food and Drug Administration)
§ 177.1550 dissolution test
・Operating temperature (fixed usage): Air, Inert gas: -65 to 200°C
Water: 0 to 100°C (No freezing)
＊This may vary according to size.
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color |
|---|---|---|---|
| TH/TIH | φ4, φ6, φ8, φ10, φ12 | φ1/8''，φ3/16''，φ1/4''，φ3/8''，φ1/2''，φ3/4'' | Translucent, Black, Red, Blue |
Soft Fluoropolymer Tubing TD/TID
Fittings and Tubing » Tubing(Fluoropolymer/Clean)
-
・Max. operating pressure: 1.6 MPa (at 20℃)＊
・Food Sanitation Law compliant
・Complies with the FDA (Food and Drug Administration)
§ 177.1550 dissolution test
・Operating temperature (fixed usage): Air, Inert gas: −65 to 260℃
Water: 0 to 100℃ (No freezing)
＊This may vary according to size.
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color |
|---|---|---|---|
| TD/TID | φ4，φ6，φ8，φ10，φ12 | φ1/8''，φ3/16''，φ1/4'' φ3/8''，φ1/2'' | Translucent |
2-Layer Soft Fluoropolymer Tubing TQ
Process Valves » Valves for Water and Chemical Base Fluids
-
・Carries fluid such as solvent with a soft and abrasion resistant tube.
・2-layer structure
Outer layer: Special nylon resin
Inner layer: Special fluoropolymer
・Internal smoothness: Equivalent to Ra 0.02 μm
| Series | Tubing O.D. Metric size | Color | Fluid |
|---|---|---|---|
| TQ | φ4, φ6, φ8, φ10, φ12 | Translucent (Material color) | Air, Water, Inert gas, Solvent |
Fluoropolymer Tubing TL/TIL
Fittings and Tubing » Tubing(Fluoropolymer/Clean)
-
・Max. operating pressure: 1.0 MPa (at 20℃)
・Operating temperature (fixed usage): −65 to 260℃
Fluoropolymer Tubing (PFA) TLM/TILM
Fittings and Tubing » Tubing(Fluoropolymer/Clean)
-
・Operating temperature (fixed usage): Air, Inert gas: −65 to 260℃
Water: 0 to 100℃ (No freezing)
・Food Sanitation Law compliant
・Complies with the FDA (Food and Drug Administration)
§ 177.1550 dissolution test
| Series | Tubing O.D. Metric size | Tubing O.D. Inch size | Color |
|---|---|---|---|
| TLM/TILM | φ2，φ3，φ4，φ6，φ8，φ10 φ12，φ16，φ19，φ25 | φ1/8''，φ3/16''，φ1/4''，φ3/8'' φ1/2''，φ3/4''，φ1''，φ1 1/4'' | Translucent, Black, Red, Blue |
