Linear Guide Parallel Type Air Gripper MHZ□2
Rotary Actuators/Air Grippers » Parallel Type Air Grippers
-
・The linear guide improves rigidity and accuracy.
・Dustproof and drip proof construction
・Dust cover material is selectable.
Safety Instructions Air Grippers/Precautions
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
| Type | Series | Cylinder bore size (mm) |
|---|---|---|
| Compact | MHZA2-6 | 6 |
| Compact, with dust cover | MHZAJ2-6 | 6 |
| Standard | MHZ2 | 6，10，16，20，25，32，40 |
| Long stroke | MHZL2 | 10，16，20，25 |
| Long stroke, with dust cover | MHZL2 | 10，16，20 |
| With dust cover | MHZJ2 | 6，10，16，20，25，32，40 |
Slide Guide Round Body Air Gripper 2-Finger Type MHS2
Rotary Actuators/Air Grippers » Parallel Type Air Grippers
-
・Vertically compact and lightweight due to the wedge shaped cam construction
・Ideal for operations in which external force is applied, such as press
fitting operations
・Repeatability: ±0.01 mm
Safety Instructions Air Grippers/Precautions
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper
Green Procurement (RoHS)
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper
Green Procurement (RoHS)
| Series | Cylinder bore size (mm) |
|---|---|
| MHS2 | 16，20，25，32，40，50，63 |
Slide Guide Round Body Air Gripper 3-Finger Type MHS3
Rotary Actuators/Air Grippers » Parallel Type Air Grippers
-
・Vertically compact and lightweight due to the wedge shaped cam construction
・Ideal for operations in which external force is applied, such as
press fitting operations
・Repeatability: ±0.01 mm
・Long stroke type: Strokes 2 times longer than the standard type
・Gripping of cylindrical workpieces
・Reliable removal of the workpiece with through-holes and a center pusher
Safety Instructions Air Grippers/Precautions
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
| Type | Series | Cylinder bore size (mm) |
|---|---|---|
| Double acting | MHS3 | 16，20，25，32，40，50，63，80，100，125 |
| Single acting | MHS3-X84 | 16，20，25，32，40，50，63 |
| With dust cover | MHSJ3 | 16，20，25，32，40，50，63，80 |
| Through-hole | MHSH3 | 16，20，25，32，40，50，63，80 |
| With dust cover + Through-hole | MHSHJ | 16，20，25，32，40，50，63，80 |
| Long stroke | MHSL3 | 16，20，25，32，40，50，63，80，100，125 |
Slide Guide Round Body Air Gripper 4-Finger Type MHS4
Rotary Actuators/Air Grippers » Parallel Type Air Grippers
-
・Vertically compact due to its wedge shaped cam construction
・Optimally holds rectangular workpieces for positioning operations
・Repeatability: ±0.01 mm
・Positioning of rectangular workpieces
Safety Instructions Air Grippers/Precautions
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
Auto Switches/Precautions Air Grippers Series Variations/Model Selection
Quick Selection Table Made to Order Air Gripper Green Procurement (RoHS)
| Series | Cylinder bore size (mm) |
|---|---|
| MHS4 | 16，20，25，32，40，50，63 |
