Air Preparation Equipment

|Water drop removal air


・Air blowing (Simple removal of particles)
・General pneumatic tools

■Air Preparation System

Click the model name to see detailed product information.

AT,HAA/HAW:Not required when attached to air compressors.
AT:Required for screw compressors when it is used to accumulate pressure.

■Impurity in compressed air
Moisture Filtration Oil mist density
Node 1)
Oil odor Quality grade as
system Note 2)
Dew point Moisture content
Atmospheric pressure dew point:6℃
Pressure dew point:40℃(At 0.7 MPa)
7g/㎥(ANR) 3μm
(Filtering efficiency 99%)
Yes 4,-,-

Note 1) When the inlet oil mist density (compressed air density) is approximately 30 mg/m3 (ANR) or less.
Note 2) This describes the grade of compressed air quality based on ISO8573-1: 2010 (JIS B8392-1: 2012), which is the maximum quality grade for the system. It varies, however, depending on the inlet air conditions.
