・Compact and lightweight
56 mm x 40 mm x 90 mm (H x W x D)
Weight: 340 g (In the case of LFE1□3)
・Backflow can be detected
・Fluid temperature: 0 to 85℃
・Current consumption: 45 mA
・Applicable fluid: Water, water-soluble coolants
|Series||Rated flow range (L/min)|
0.5 to 20
2.5 to 100
5 to 200
・Operating fluid temperature: 0～85℃
educed by up to 10% when the display is off.
・Applicable fluids: Water, Water-soluble coolant
・Reverse flow can be detected. Reverse flow error display
・Repeatability: ±1.5%F.S.（Analog output）
・Flow direction can be changed after installation.
■Default flow direction (Normal flow)
■Flow direction can be changed after installation.
