NEW

2/3-Port Mechanical Valve
with One-touch Fitting
VM100F Series Updated Jun-18

Built-in One-touch fitting reduced installation space and less piping work
Space saving
Built-in One-touch fitting Approx. 35% reduction
Lightweight
With resin body material 80% reduction (48 g lighter)
Less man-hours replacing the actuator
Mounting using a clip makes replacement easier.

See Catalogs

Wireless System
EX600-W Series Updated Feb-18

Usable even in welding environments
Noise resistance
Uses the 2.4 GHz ISM frequency band
Frequency hopping: Every 5 ms
High-speed connection: From power supply ON to start of communication: Min. 250 ms
Communication response: Signal response time: 5 ms
Communication cables not required
Number of I/O points: Max. 1280 inputs/1280 outputs

See Catalogs

Fieldbus System
EX245 Series Updated May-17

AIDA^* specifications compliant
*Abbreviation of the Automation Initiative of German (Deutschland) Automobile Manufacturers
Push Pull connectors
One-touch installation and removal
Reduced wiring time
Modules can be combined flexibly.

See Catalogs

Plug-in 5 Port Solenoid Valve
Terminal Block Box (Spring Type)
SY3000/5000/7000 Series Updated Sep-16

Compact
Installation area of the terminal block box Reduced by approx. 40%
Reduced work-hours!
Spring type terminal block adopted.
Crimping work using Y-terminals is not necessary.

See Catalogs

Stainless Steel
One-touch Fittings
KQ2-G Series Updated Aug-16

Metal material: Stainless steel 303
Improved tube insertion/removal Insertion force : Max. 30% reduction, Removal force: Max. 20% reduction
Compact and lightweight
Dimensions Height 24% shorter, Dimensions Length 23% shorter, Weight 57% lighter
Body type: total of 27models

See Catalogs

Hand Valve
VH22/23 Updated Jul-18

Bottom piping is now available.

See Catalogs

Hand Valve
VH24/25 Series Updated Jun-16

Side exhaust added

See Catalogs

5 Port Solenoid Valve
SY3000/5000/7000 Series Updated Mar-16

Added with residual pressure release valve and vacuum release valve with restrictor. [New]
Added the dual port EX600 EtherNet/IP™ product. [New]
Added the products for the EX500 Gateway Decentralized System 2. [New]
Added SUP stop valve spacer (with residual pressure release valve). [New]
Thanks to the flow increase, valve size can be reduced!
Saves energy and space.
Power consumption: 0.1 W (With power saving circuit) / 0.35 W (Standard)

See Catalogs

5 Port Solenoid Valve
Plug-in Type
Series S0700 Updated Feb-16

EX600 EtherNet/IP™ (Dual port product) added. [New]
EX500 EtherNet/IP™ Gateway Decentralized System 2/128 points (inputs/outputs) added. [New]
7 mm width compact solenoid valve manifold
4-position, dual 3-port valve
A variety of common wiring methods
Slim compact plug-in manifold:
Footprint reduced by 45%, Height reduced by 20 mm

See Catalogs

Fieldbus System
(Gateway Decentralized Type)
Series EX500 Updated Dec-15

Decentralized valve installation
Valves can be installed near the actuators!
Reduced piping space and piping materials
Reduced wiring space
No need to set the address for the valve manifold and Input Unit.

See Catalogs

3 Port Solenoid Valve/Residual Pressure Release Valve
with Detection of Main Valve Position
Series VP/VG Updated Dec-15

Safety standard ISO13849-1 certified 2 (Corresponding to category 2 to 4)
With detection of main valve position
Redundant system can be constructed easily.
Highly reliable construction
Safety limit switch can be selected.
With soft start-up function (-X555)

See Catalogs

3 Port 3 Position Valve
Pilot Solenoid/Air Operated
Series VEX3 Updated Nov-15

Intermediate stopping of cylinders up to o125 is possible.
Power consumption: 1 W
3 Manual override options added
Locking slotted type [New]
Push-turn locking slotted type [New]
Push-turn locking lever type [New]

See Catalogs

5 Port Solenoid Valve
Series VQ4000/5000 Updated Oct-15

Compact and large flow capacity
Installation volume: 42% Reduction, Installation area 26% Reduction
VQ4000: Possible to drive cylinders up to φ160
VQ5000: Possible to drive cylinders up to φ180
Power saving Power consumption: 0.4 W (Low wattage type)
Long service life: 100 million cycles (According to SMC life test conditions)

See Catalogs

5 Port Solenoid Valve
Series VQC4000/5000 Updated Oct-15

Compact and large flow capacity
VQC4000: Possible to drive cylinders up to φ160
VQC5000: Possible to drive cylinders up to φ180
Extensive range of protocols available
Power saving Power consumption: 0.4 W (Low wattage type)
Long service life: 100 million cycles (According to SMC life test conditions)
Enclosure IP67 compliant

See Catalogs

Plug-in Vacuum Release Valve with Restrictor
Only for External Pilot
SY3A□R/SY5A□R Updated Jul-15

Vacuum suction and release can be controlled with a single valve!
Can be mounted on the same manifold with the standard valve.
* When the individual EXH spacer is used.

See Catalogs

Fieldbus System (For Input/Output)
Series EX600 Updated May-15

New Unit type added: SI Unit (EtherNet/IP^TM) [New]
IP67 (Some products are IP40)
Reduction in wiring time with SPEEDCON (Phoenix Contact).
Just insert and make 1/2 rotation!
Self Diagnosis Function
Max. 9 Units, Can be connected in any order

See Catalogs

5 Port Solenoid Valve/Plug Lead Type
Series S0700 Updated Apr-15

Body ported[New]
Valve width: 7.4 mm
Possible to drive cylinders: Up to o32 (Body ported)
Power consumption: 0.35 W
Weight: 39 g

See Catalogs

Plug-in Type
SUP Stop Valve Spacer:
With Residual Pressure Release Valve/Lever Type
SY30/50/70M-50-1AE Updated Aug-14

Lever type is added to manual override button!
Solenoid valves can be replaced individually
without shutting off the main pressure!
Air for solenoid valves can be shut off individually!
Solenoid valves can be replaced individually!

See Catalogs

Foot Pedal Type 5 Port Mechanical Valve
XT34-60/67 Updated Aug-14

5 port is added to the foot pedal type mechanical valve.
Models with lock and without lock are available.

See Catalogs

High Speed 2 Port Valve
Series SX10 Updated Feb-14

High speed response : ON/0.45 ms, OFF/0.4 ms (±0.05 ms)
Long service life : 5 billion cycles or more
High frequency : 1200Hz
Width : 9mm
Low power consumption : 4W

See Catalogs

2/3 Port Mechanical Valve
Series VM100/200 Updated Aug-13

Lightweight
VM100: 60 g (Conventional model: 95 g) VM200: 90 g (Conventional model: 111 g)
Mounting interchangeable with the conventional model
Available in vacuum applications
VM100: -100 kPa to 1 Mpa (VM200: 0 to 1 MPa)
Mounting: Bracket mounting [New], bottom mounting [New], Side mounting, Panel mounting
Piping direction: Side ported, Bottom ported (VM100 only)
With miniature indicator
Possible to check if air is output to the secondly port.

See Catalogs

3 Port Solenoid Valve
Series VP300/500/700 Updated Jul-13

Low wattage specification added [New]
Power consumption is reduced.
Built-in full-wave rectifier (AC)
Longer life expectancy: 50 million cycles or more
Built-in strainer in the pilot valve
Air Operated Valve Series VPA300/500/700

See Catalogs
